Description

For those seeking Ashdown tone, power and reliability without the weight, the RM-500 EVO II is the solution. Perfect for small, medium and even larger shows when paired with the right cabinets.
Features
New on-board headphone preamp
Passive and active input jack socket for use with high and low output instruments
Tone shape button
5-band EQ
On-board compressor
Drive control
Sub harmonic controls
Mute button
Specifications
Power Output: 500 Watts
Power Requirement: 115-230 Volts
Speaker Outputs: 2 x Neutrik Speakon/Jack outputs
Frequency Response: -3dB @ 17Hz und 30KHz
High Instrument Input: Impedance 3.9m Ohms, input range 150mV
Low Instrument Input: Impedance 10k Ohms, input range 300mV – 40V p-p
Line Input: Impedance 22k Ohms, input level 0dBu nominal
DI Output: 600 Ohm balanced, Level 0dBu nominal
Tuner Output: Impedance 22k Ohms, Level 0dBu nominal
Impedance: Minimum 4 Ohms
Signal to noise: Better than 80dB (EQ flat)
EQ: Bass +/-15dB @ 100Hz Lo Mid +/-15dB @ 220Hz Middle +/-15dB @ 660Hz Hi Mid +/-15dB @ 1.6kHz Treble +/-15dB @ 7kHz shelving Deep +
Effects Send: Impedance 22k Ohm, Level 0dBu nominal
Effects Return: Impedance 22k Ohms, Input Level 0dBu Nominal
Distortion: Less than 0.5% THD
Dimensions (H x W x D): 86 x 314 x 235mm
Weight: 2.1 kg/4.6 lbs
