Description

Vintage Analog BBD Delay Pedal with Max. 1000 ms Delay Time and MIDI Control.

Features

Classic, warm, and rich analog delay with up to 1,000 ms of delay time
Authentic recreation of the Moog MF-104Z from the ’90s
Feedback control for repeats
Delay Time control for precise timing
MIDI control for ultimate control and flexibility
Mix control for blending between dry and delayed signals
Drive control for input gain
Spillover mode for smooth transitions between delay on/of
Expression pedal input for real-time control
Compact and rugged design for easy transport and onstage use
Combine with other pedals for even more creative possibilities

Specifications

– Connector: 1 x 1/4″ TS, unbalanced
– Impedance: 1 M
– Output impedance: 600
– Connector: 1 x 1/4″ TRS, unbalanced
– Output impedance: 440
– Input impedance: 140 k
– Connector: 1 x 1/4″ TRS
– Impedance: 180 k, unbalanced
– CV input range: 0 V to +5 V
– Impedance: 34 k, unbalanced
– MIDI in: 2 x 5-pin DIN, 16 channels
– Drive: 1 x rotary knob
– Output level: 1 x rotary knob
– Mix: 1 x rotary knob
– LFO: 1 x rotary knob
– Rate: 1 x rotary knob
– Amount: 1 x rotary knob
– Delay time: 1 x rotary knob
– Short / long: 1 x rocker switch
– Feedback: 1 x rotary knob
– Tap tempo: 1 x footswitch
– Bypass: 1 x footswitch
– Frequency response: 20 Hz to 20 kHz (+0 / -2 dB)
– Dynamic range: 83 dB
– Signal-to-noise ratio: 73 dB
– Overall gain: +33 Db
– Power input: Standard 9 V DC, centre negative,> 400 mA (power supply not included)
– Power consumption: 1.8 W
– Dimensions: 85.9 x 147.6 x 196.9 mm (3.38 x 5.81 x 7.75″)
– Weight: 1,100 g (38.8 oz)
