Description

AKG D7

Dynamic Vocal Microphone, Superning Characteristic, Varimotion Membrane, Mechano-Pneumatic Case Lager, Brumm Compensation Coil, Built-in High Pass Filter at 80 Hz, spring steel lattice cap, 70 – 20,000 Hz, 147/156 DB SPL (THD = 1% / 3%), incl. Tripod adapter, replacement Inner wind protection and case

The AKG D7 is an outstanding vocal microphone for tough stage use. It is resilient and transmits even very loud signal levels without distortion (up to 156 dB). Thanks to the patented Varimotion diaphragm, the sound quality of the AKG D7 is exceptionally high and even surpasses many condenser microphones.

Dynamic microphones often sound compressed and muffled. AKG has therefore developed a diaphragm with different thicknesses at the edge and in the middle. This significantly improves the vibration and impulse response of the AKG D7. The sound becomes more transparent and the resolution more detailed. A slight boost in the midrange and treble frequencies also ensures that the voice really comes through in the mix.

The AKG D7 has a supercardioid polar pattern. This makes the microphone insensitive to ambient noise and feedback. To make the AKG D7 insensitive to noise (e.g. from a guitar amplifier), a high-pass filter and a hum compensation coil are built in. They ensure a clean sound.

To reduce/avoid handling and cable noise, the microphone capsule is elastically mounted. Popping sounds and breathing noises are effectively suppressed by the windscreen integrated in the microphone basket.

The housing of the AKG D7 is made of metal and has a scratch-resistant lacquer finish. This makes it very resistant and robust. A stand holder, a replacement inner windscreen and a case are included.

The microphone is also available with a click-free on/off switch as the AKG D7 S.

• Extremely robust vocal microphone
• Hum-cancelling coil integrated in capsule
• Laminate Varimotion diaphragm
• Spring steel grille cap
• Gold-plated XLR output
• Includes padded soft case, stand connector and spare windscreen
• Model versions with and without on/off switch
• Polar pattern: supercardioid
• Frequency response: 70 Hz – 20 kHz
• High-pass filter: 80 Hz
• Transfer factor: 2.6 mV/Pa
• Limiting sound pressure level: 156 dB SPL
• Equivalent sound pressure level: 18 dB-A
• Signal-to-noise ratio: 76 dB
• Impedance: <= 600 Ohm
• Load impedance:>= 2000 Ohm
• Connection: XLR connector
• Dimensions: 185 mm, Ø 51 mm
• Weight: 340 g
