Tascam US-2X2HR

All-rounder for demanding people

The US-2x2HR is a high-resolution USB audio interface from Tascam’s US-HR series. It offers two switchable mic/line/instrument inputs and two balanced line outputs, as well as MIDI in and out for your Windows or Mac computer or your iPhone or iPad. This interface is ideal for music production and home recording with high demands on ease of use and studio-quality sound. However, the built-in loopback function and support for Open Broadcaster Software (OBS Studio) also make it an excellent choice for creating podcasts and live streaming applications.

Lower noise and less distortion – better sound than ever before The compact US-2x2HR impresses with many performance features such as high resolution up to 24 bit and 192 kHz sampling rate, extremely low latency with a Windows buffer size from four samples and Ultra HDDA microphone preamplifiers with 48 volt phantom power for excellent sound quality with extremely low noise . There’s also a robust USB-C port and a wide range of included software so you can start recording and producing straight away.

The US-2x2HR is also suitable for mobile production or live streaming via your iPhone or iPad* with the included Cubasis LE. Simply put, the US-2x2HR lets you create and distribute great-sounding audio wherever you are.

Tascam US-2x2HR

Ease of use is key

All US HR models have a unique cast aluminum honeycomb structure on the side panels. This concept not only provides a slim, eye-catching design, but also just the right weight so that the interface doesn’t move when you connect or remove cables. Equally important: the sides are angled and the user interface, which is tilted upwards, is ergonomic and easy to use.

If you are a musician, producer or home recorder looking for a solid, clear and user-friendly audio interface with excellent sound quality, the Tascam US-2x2HR can be your loyal partner for many years.

*When used with an iPhone or iPad, an optional battery pack or AC adapter is required.

Main features at a glance

• Further developed version of our popular US-2×2 with even improved sound quality
• Provides a Windows or Macintosh computer or an iOS device with two audio inputs, two audio outputs, and a MIDI interface
• Sampling rates up to 192 kHz at 24 bit resolution
• USB Audio Compliance 2.0 for connection to iOS devices

Hardware features

• Two microphone/line inputs via balanced combination sockets (XLR/jack)
• High quality Ultra HDDA microphone preamplifiers with extremely low input noise (EIN: -128 dBu)
• Wide input gain range of 56 dB, also suitable for weaker dynamic microphones
• Switchable 48-volt phantom power for the XLR inputs
• Jack inputs 1/2 switchable to instrument level for direct connection of a guitar or bass
• Two line outputs (6.3 mm jack socket, 3-pin, balanced)
• Direct listening function for low latency listening
• Monitor Mix control determines the ratio between the signals from external devices and the signal coming from the computer
• Headphone output with 18 mW output power per channel
• Separate level controls for line and headphone output
• MIDI input/output

• Powered via USB, ideal for recording on the go
• Standalone operation as a simple preamplifier for rehearsals and more
• Robust aluminum housing
• Housing shape enables slanted installation with easy accessibility

Software features

• In-house developed Windows driver ensures stable operation with low latency
• Buffer size for Windows now selectable from 4 samples to enable a recording environment with extremely low latency
• Each input can be switched on/off separately
• Input monitoring selectable mono/stereo
• You can choose which signals are output at the line outputs
• A loopback function makes it possible to combine two audio channels coming from the computer with the input signals and send this mix to the Streaming or communications software
  • Input and computer signals each selectable mono/stereo
  • Adjust the transmission level using a slider
• Automatic update function for software, driver and firmware updates (the update process can be initiated at the push of a button)
• Included in delivery: Cubase LE, Cubasis LE3, IK Multimedia SampleTank 4 SE, Antares Auto-Tune Unlimited (3 months free use)
• Compatible with common DAW applications (Pro Tools, Live, Cubase, Studio One, GarageBand)
