Description

This VM95 Series cartridge with 2.2 x 0.12 mil Microlinear stylus fits half-inch mount turntables. The cartridge offers excellent channel separation and low distortion for outstanding tonal quality. The durable, low-resonance housing includes threaded inserts that enable the cartridge to be mounted to the headshell with just two screws no nuts required. And since all VM95 Series share the same body, the stylus can be replaced with any of the six interchangeable AT-VMN95 replacement styli.
Features
VM Series dual magnet cartridge with 2.2 x 0.12 mil Microlinear stylus
Aluminum cantilever
Durable low-resonance polymer housing
Threaded inserts in cartridge body enable cartridge to be mounted to headshell with just two screws no nuts required
Compatible with any AT-VMN95 replacement stylus
Specifications
Frequency Response: 20-25,000 Hz
Channel Separation: 23 (dB at 1 kHz)
Vertical Tracking Force: 1.8-2.2 g (2.0 g standard)
Stylus Construction: Nude square shank
Recommended Load Impedance: 47,000 ohms
Output: 3.5 mV (1 kHz, 5 cm/sec.)
Channel Balance: 1.5 dB (1 kHz)
Stylus Shape: 2.2 x 0.12 mil Microlinear
Cantilever: Aluminum pipe
Mount: Half-inch
Replacement Stylus: AT-VMN95ML
Coil Impedance: 3.3 k ohms (1 kHz)
DC Resistance: 485 ohms
Load Capacitance: 100 to 200 pF
Coil Inductance: 550 mH (1 kHz)
Vertical Tracking Angle: 23 degrees
Dimensions: 17.2 mm (0.68″) H 18.9 mm (0.74″) W 28.3 mm (1.20″) D
Weight: 6.1 g (0.22 oz)
Accessories Included: Two 11 mm installation screws, two 8 mm installation screws, two washers, nonmagnetic screwdriver
